High Insulation Flanged Plastic Box Corrosion Resistance CE / RoHS Approved
Fixed ear plastic waterproof box adopts quality ABS engineering plastic or polycarbonate (PC) material,suitable for electrical and electronic control equipment ,shipbuilding ,petrochemical industry ,large factories, coastal factories ,terminal water treatment facilities ,all kinds of natural disaster prevention equipment in harsh industrial environment.product adopt plastic bolt design,prevent loss effectively.1/4 weight of metal box ,impact resistance ,corrosion resistance,long life ,good insulation performance ,easy processing.
| Model | M2-121005G |
| Material | ABS |
| Color | Industrial Grey(can be customized) |
| Dimension | 125*100*52mm(see below other dimensions) |
| Screws | Nickel |
| Protection Level | IP65 |
| Temperature Range | -40℃~+120℃ |
| Hole Drilling | Available |
| Cable Gland | Available |
| Inside Mounting Plate | Available |
| Logo Print | Available |
| Wall Mounting Ears | Available |
| Trading Terms | EXW, FOB, CIF, CFR etc. |
| Payment Terms | Paypal, T/T, L/C |
| Shipping Port | Ningbo or Shanghai |
| Transportation | Express(small QTY), Sea/Air(large QTY) |
| Sample | Available |
Sizes available.
| Model | Dimension |
| M2-060503G | 64*58*35 |
| M2-060503T |
| M2-080503G | 83*58*33 |
| M2-080503T |
| M2-100604G | 100*68*40 |
| M2-100604T |
| M2-100605G | 100*68*50 |
| M2-100605T |
| M2-110803G | 115*85*35 |
| M2-110803T |
| M2-110905G | 115*90*55 |
| M2-110905T |
| M2-110906G | 115*90*68 |
| M2-110906T |
| M2-121005G | 125*100*52 |
| M2-120806G | 120*81*65 |
| M2-120806T |
| M2-150904G | 158*90*46 |
| M2-150904T |
| M2-150906G | 158*90*64 |
| M2-150906T |
| M2-161609G | 160*160*90 |
| M2-161609T |
| M2-201207G | 200*120*75 |
| M2-201207T |
| M2-231508G | 230*150*87 |
| M2-231508T |
We also produce other type of boxes, hinged ones, lockable ones, aluminum ones and so on.
Details:
Application:
Fixed ear plastic waterproofroof box adopts quality ABS engineering plastic or polycarbonate (PC) material,wuitable for electrical and electronic control equipment ,shipbuilding ,petrochemical industry ,large factories, conastal factories ,terminal water treatment facilities ,all kinds of natural disaster prevention equipmne in harsh industrial environment.product adopt plastic bolt design,prevent loss effectively.1/4 weight of metal box ,impact resistance ,corrosion resistance,long life ,good insulation performance ,easy processing.
Advantages
1.The product weighs approximately 1/4 the weight of an iron box and can be easily installed or
moved,The product is free from corrosion,carries superior insulation.
2.The Product has passed waterproof and dustproof carried out under rigid quality standards. (IP 65)
3.The use is also convenient for the installation of Terminal Substitution Rail, Button Box, Small
Terminal, Signal , Relay and Sensor ,Communication and joint Box etc.
4.High quality waterproof box series, new imported materials, no recycled material. Good
strength. Can do transparent and opaque or PC material , with corresponding backplate for
choice.
